$799.99
Regular price$999.99
In-Stock and Ready to Ship
Ask an Expert
Fast & Free Shipping
Hassle-Free Returns
Expert Service
Description
Highlights
- Expanded Modeling Technology
- 300 Programs (200 Preset / 100 User)
- Dynamic 16-Band Vocoder
- Intuitive Virtual Patch System
- Three Oscillators with 138 Types
- 18 Filter Types
- Powerful Effects Section with 18 Types
- Compact Design with 37 Velocity-Sensitive Keys
Specifications
| Sound generation system: | XMT (eXpanded Modeling Technology) |
| Programs: | 300 programs (200 preset / 100 user) |
| Number of categories: | 8 categories |
| Timbres: | Max 2 timbres (Layer / Split) |
| Maximum Polyphony: | 24 voices max |
| Synth Oscillator Structure: | 3 oscillators (choose from analog, noise, DWGS, PCM, and MIC IN types) |
| Number of types: | 138 types (32 analog and noise, 40 DWGS, 65 PCM, 1 MIC IN) |
| Filter Structure: | 1 filter (choose from LPF, HPF, BPF) |
| Number of types: | 18 types (7 LPF, 5 HPF, 6 BPF) |
| Modulation Structure: | EG: 2 units, LFO: 2 units |
| Routing: | Virtual patches: 6 sets |
| Effects Sections: | Program effects x 3 (PRE FX, MOD FX, REV/DELAY) + EQ (2Band) |
| Types: | PRE FX: 6 types, MOD FX: 6 types, REV/DELAY: 6 types |
| Vocoder: | 16-band vocoder, formant shift function, formant hold function |
| Arpeggiator: | Up to 8 steps, 6 types (UP/DOWN/ALT1/ALT2/RANDOM/TRIGGER) |
| Audio Input: | Mic jack Connector XLR type (balanced) Maximum level +2 dBu |
| Output: | OUTPUT (L/MONO, R) jacks Connectors φ6.3 mm TS phone jacks (unbalanced) L/MONO, R Load impedance 10 kΩ or higher Maximum level +5 dBu |
| Headphone jack: | Connector φ6.3 mm (1/4") stereo phone jack Maximum level 60 mW + 60 mW @ 33 Ω |
| Displays: | Main 16 x 2 character OLED display OSCILLATOR, FILTER 128 x 64 pixel OLED display Keyboard 37 keys (velocity sensitive) |
| Controllers: | Internal Joystick, OCTAVE UP/DOWN buttons, category/favorites buttons |
| Inputs: | DAMPER jack (half-damper not supported), SWITCH/PEDAL jack External connections MIDI IN, MIDI OUT, USB B connector |
| Power supply: | AC adapter jack (DC 12 V) |
| Power consumption: | 9 W |
| Dimensions (width x depth x height): | 565 x 338 x 92 mm / 22.24" x 13.31" x 3.62" |
| Weight: | 3.1 kg / 6.83 lb. |
| Operating temperature range: | 0 – +40 °C (non-condensing) |
| Included items: | Quick Start Guide, Precautions, AC Adapter, Vocoder mic, windscreen |
| Options: | XVP-20: Expression/volume pedal, EXP-2: Foot controller, DS-1H: Damper pedal, PS-1, PS-3: Pedal switch |
