Description
Highlights
Specifications
| Input: | Standard ¼” mono cable connection. |
| Headphone Output: | Analog cabinet emulation for headphones. |
| Passive/Active: | Switch between passive and active modes. |
| Compression: | Dynamic compression control with automatic makeup gain. |
| Drive: | Adjust distortion levels with drive modes. |
| Blend: | Mix between Clean and Distortion signals. |
| Level: | Controls Microtubes Engine’s output volume. |
| Low: | ±12 dB @ Low shelf |
| Low Mids: | ±12 dB @ 500 Hz/1 kHz |
| Hi Mids: | ±12 dB @ 1.5 kHz / 3 kHz |
| Treble: | ±12 dB @ High shelf |
| Master: | Controls overall volume with Mute. |
| AC Power ON/OFF: | Power ON the combo. |
| AC Socket: | Electric power connector (100 – 230 VAC, 50-60Hz). |
| Tweeter: | Toggle tweeter ON/OFF. |
| Pre/Post: | Select clean DI or processed signal. |
| DI Output: | Send signal to console, mic preamp, etc. |
| Ground Lift: | Lift ground of XLR output. |
| Aux In: | Connect to headphone output of devices. |
| Return: | Receive signal from outboard gear. |
| Send: | Send signal to outboard gear. |
| Footswitch: | Connect Darkglass footswitch. |
| External Speaker: | Connect to external speaker cabinet. |
| Woofers: | Custom Design Eminence Speaker |
| Horn: | Eminence Tweeter |
| Cabinet Material: | Balsa Wood |
| Power Rating RMS: | 500 Watts |
| Dimensions: | Width: 46.5 cm / 18.3″, Depth: 61.1 cm / 24″, Height: 39.5 cm / 15.55″, Weight: 17.3 kg / 38.13 lb |
